PAX FD

  • Bi-directional type for wireless communication
  • Jamming detection and communication channels encryption
  • Wireless communication range(open space) – up to 1500m
  • Signal strength indication (RSSI)
  • Standard type of batteries – CR123A
  • 24-hour fire alarm supervised zone
  • Rate-of-rise heat part, 10°C/min (max 60°C)
  • Optical chamber auto compensation
  • Tamper switch for self-protection of the box
  • Events transmitted: Fire, Tamper activation, Low battery
  • Installation method – Indoors
Category:

PAX FD is a wireless combined fire alarm detector – with optical smoke and heat parts. The detector is compatible for operation with:

  • BRAVO Next wireless control panel, for building of fully wireless security systems.
  • PAX WL Expander module, for building of hybrid security systems with Eclipse series control panels.

The exceptional performance of the detector is possible, thanks to our improved wireless communication protocol Beacon+.

System element Periphery
Product type Indoors
Technology type Wireless
